Router 4g - Cpe Antena Zte Modelo :wf- 820+ Solo: Claro

Descripción

4G LTE CAT4 CPE B42/43/48 (3.5Ghz/3.7Ghz)+multiband CW0200B ODU+AP - COMPATIBLE SOLO CON OPERADOR CLARO

Product introduction
CW0200B 4G wireless router ODU+AP is a high performance LTE CPE solution, base on Sequans platform. Which can work at B42/43/48 (3.5Ghz/3.7Ghz)+multiband simultaneously, with high gain antenna, support Tr069, Ipv6/Ipv4 dual stack and Multi-APN etc. Here’s the main feature of the product.

CAT4
2x2 mimo
3GPP Release 9
Tr069
IP65
POE
802.11 b/g/n
VoIP/VoLTE
Ipv6/Ipv4 dual stack
Multi-APN
PCI lock (Cell lock)
Software Upgrade http/FTP Auto Upgrade
Bridge Mode/Router Mode/NAT Mode

Product Parameters:
Spec

Description

LTE chip set

Sequans SQN3220+SQN3242

TxRx

1T2R

MIMO

2x2

WIFI

2.4GHz, 802.11b/g/n

WIFI User

32

Network Management

TR069/SNMP

Interface ODU RJ45x1
AP RJ45 x 4 + RJ11 x 2(or RJ45 x 4 only) (optional)
Voice

VoIP/VoLTE/None (optional)

Power Supply

100~240V AC

Maximum Power Consumption

<14W

IP rating

IP65 (ODU)

LED ODU Power/Mode/Signal Strength
AP Power/WiFi/WPS/Voice/Mode/Signal Strength/LAN Indicator
USIM

Support 1.8V/3.0V 2FF USIM

Antenna

Build in 1T2R dual-polarized directional antenna

Support bands

Band 42/43 + multiband
FDD Band 3/4/5/7/12/17/20/28
TDD Band 38/39/40/41/42/43/48

Output
Power@25¿

23±2 dBm

Receiving
Sensitivity B3/28/41 -93dBm
B1/4/38/39/40 -96dBm
B5 -97dBm
B2/7 -94dBm
B8/12/17 -96dBm
B20 -92dBm
B42/43/48 -95dBm
LTE Antenna
Gain B28 3dBi
B5/8/12/17/20 6dBi
B1/2/3/4/39 9dBi
B/7/38/40/41 11dBi
B42/43/48 14dBi
ODU dimension

280x164x56mm

AP dimension

167x187x75mm

ODU weight

800g

AP Weigh

310g
